Solar Breaker Pakistan
-
6KW Hybrid Solar DB Bundles With Steel Body for Single PV Sting
- Rs.12,285
Rs.14,275- Rs.12,285
- Unit price
- per
6KW Hybrid Solar DB Bundle Steel Body (Single PV String) is a hybrid solar DB bundle for Pakistan that protects the solar side, load side, and battery-ready switching side more intelligently than a basic on-grid board. Starting from Rs.12,285, it is designed for buyers...- Rs.12,285
Rs.14,275- Rs.12,285
- Unit price
- per
-
DC MTS 2 Pole 125A | Battery Transfer
- Rs.6,000
Rs.6,500- Rs.6,000
- Unit price
- per
DC transfer switch 2 pole 125A is the right product when you need to manually shift a battery or DC load from one source to another without messy improvised switching. On the current CNC Electric Pakistan listing, this DC MTS item is shown at...- Rs.6,000
Rs.6,500- Rs.6,000
- Unit price
- per
-
DC 4 Pole MCB 1500V | Solar PV Breaker
- Rs.3,800
Rs.4,220- Rs.3,800
- Unit price
- per
DC MCB 4 pole 1500V is used where a solar DC circuit needs compact overcurrent protection instead of a larger MCCB. This 32A model is listed at Rs.3,800 on CNC Electric Pakistan. It suits PV strings, combiner boxes, battery-linked DC boards, and other high-voltage...- Rs.3,800
Rs.4,220- Rs.3,800
- Unit price
- per
-
DC Isolator 32A YCDCS-EL 2P/4P | Wall-Mounted Solar PV Safety Switch
- Rs.6,200
Rs.6,900- Rs.6,200
- Unit price
- per
Need a DC isolator for a solar PV system in Pakistan? The CNC Electric YCDCS-EL 32A wall-mounted DC isolator comes in two real variants: 2 Pole at Rs.6,200 and 4 Pole at Rs.7,000. Both are rated for DC 1200V and 32A, and are designed...- Rs.6,200
Rs.6,900- Rs.6,200
- Unit price
- per
-
3KW Hybrid Solar DB Bundle Steel Body - Smart Energy Control & Protection
- Rs.12,285
Rs.14,750- Rs.12,285
- Unit price
- per
3KW Hybrid Solar DB Bundle Steel Body is a 3kw hybrid solar db solution for buyers who want a complete, pre-matched protection board instead of collecting random parts from the market. Starting from Rs.12,825, this bundle is built for Pakistan where WAPDA fluctuation, load...- Rs.12,285
Rs.14,750- Rs.12,285
- Unit price
- per
-
6KW Hybrid Solar DB Bundles With Steel Body for Double PV Sting
- Rs.17,275
Rs.20,275- Rs.17,275
- Unit price
- per
6KW Hybrid Solar DB Bundle Steel Body (Double PV String) is a hybrid solar DB bundle for Pakistan that protects the solar side, load side, and battery-ready switching side more intelligently than a basic on-grid board. Starting from Rs.17,275, it is designed for buyers...- Rs.17,275
Rs.20,275- Rs.17,275
- Unit price
- per
-
6KW Hybrid Solar DB Bundle with Plastic Body for Single PV Sting
- Rs.10,775
Rs.12,275- Rs.10,775
- Unit price
- per
6KW Hybrid Solar DB Bundle Plastic Body (Single PV String) is a hybrid solar DB bundle for Pakistan that protects the solar side, load side, and battery-ready switching side more intelligently than a basic on-grid board. Starting from Rs.10,775, it is designed for buyers...- Rs.10,775
Rs.12,275- Rs.10,775
- Unit price
- per
-
8KW Hybrid Solar DB Bundle - Safe and Durable
- Rs.18,075
Rs.20,275- Rs.18,075
- Unit price
- per
8KW Hybrid Solar DB Bundle is a hybrid solar DB bundle for Pakistan that protects the solar side, load side, and battery-ready switching side more intelligently than a basic on-grid board. Starting from Rs.18,075, it is designed for buyers in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.18,075
Rs.20,275- Rs.18,075
- Unit price
- per
-
-
Red
-
Black
DC Cable 4mm & 6mm in Red & Black | High Quality Solar & Electrical Wire - Red
- Rs.35,000
Rs.55,000- Rs.35,000
- Unit price
- per
Solar DC cable is one of the most important parts of a rooftop or ground-mounted PV system because it carries the panel-side DC current between solar modules, combiner points, isolators and the inverter. On the live CNC Electric Pakistan page, this product is sold...- Rs.35,000
Rs.55,000- Rs.35,000
- Unit price
- per
-
Red
-
Black
-
-
15KW On Grid Solar DB Bundle With VA Protection - Voltage & Ampere Protection
- Rs.31,900
Rs.33,900- Rs.31,900
- Unit price
- per
15KW On Grid Solar DB Bundle With VA Protection is a 15kw solar db pakistan solution for buyers who want a complete, pre-matched protection board instead of collecting random parts from the market. Starting from Rs.31,900, this bundle is built for Pakistan where WAPDA...- Rs.31,900
Rs.33,900- Rs.31,900
- Unit price
- per
-
25KW On Grid Solar DB Bundle with DC Surge Protection
- Rs.38,050
Rs.41,860- Rs.38,050
- Unit price
- per
The 25KW On Grid Solar DB Bundle with DC Surge Protection is a large-system solar DB bundle for commercial and industrial buyers in Pakistan. Starting from Rs.38,050, it is designed for factories, warehouses, multi-story commercial buildings, schools, and large rooftops that need properly matched...- Rs.38,050
Rs.41,860- Rs.38,050
- Unit price
- per
-
DC MCCB 125A 1000V | Solar Circuit Breaker
- Rs.4,500
Rs.5,500- Rs.4,500
- Unit price
- per
DC MCCB 125A 1000V | Solar Circuit Breaker The CNC Electric YeM6-125PV DC Molded Case Circuit Breaker (MCCB) is engineered to meet the demands of high-voltage direct current (DC) applications, including solar photovoltaic (PV) systems, battery banks, energy storage systems (ESS), and industrial DC...- Rs.4,500
Rs.5,500- Rs.4,500
- Unit price
- per
-
DC SPD 1500V 3 Pole | Solar Surge Protector
- Rs.8,600
Rs.9,700- Rs.8,600
- Unit price
- per
DC SPD 1500V is built for high-voltage solar strings, combiner boxes, and inverter DC input protection. This 3 pole version is listed at Rs.8,600 on CNC Electric Pakistan. If you are building a 1500V solar plant, this is the class of protector used to...- Rs.8,600
Rs.9,700- Rs.8,600
- Unit price
- per
-
10KW On Grid Solar DB Bundles - CNC Electric Accessories
- Rs.14,350
Rs.15,780- Rs.14,350
- Unit price
- per
10KW Solar DB Bundle (Standard — No SPD) is a practical solar db bundle option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.14,350, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.14,350
Rs.15,780- Rs.14,350
- Unit price
- per
-
15KW On Grid Solar DB Bundle with DC Surge Protection
- Rs.26,350
Rs.28,985- Rs.26,350
- Unit price
- per
15KW Solar DB Bundle with DC Surge Protection is a practical 15kw solar db option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.26,350, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.26,350
Rs.28,985- Rs.26,350
- Unit price
- per
-
10KW On Grid Solar DB Bundle With SPD - Enhanced Protection
- Rs.18,050
Rs.19,855- Rs.18,050
- Unit price
- per
10KW Solar DB Bundle with SPD is a practical solar db bundle with spd option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.18,050, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.18,050
Rs.19,855- Rs.18,050
- Unit price
- per
-
10KW On Grid Solar DB Bundle with Fuse - Advanced Fuse Protection
- Rs.20,700
Rs.22,700- Rs.20,700
- Unit price
- per
10KW Solar DB Bundle with Fuse Protection is a practical solar db with fuse option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.20,700, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.20,700
Rs.22,700- Rs.20,700
- Unit price
- per
-
12KW On Grid Solar DB Bundle With SPD - Enhanced Protection
- Rs.26,350
Rs.28,985- Rs.26,350
- Unit price
- per
12KW Solar DB Bundle with SPD is a practical 12kw solar db option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.26,350, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi, Faisalabad, and...- Rs.26,350
Rs.28,985- Rs.26,350
- Unit price
- per
-
15KW On Grid Solar DB Bundle With Fuses - Advanced Fuse Protection
- Rs.32,050
Rs.37,500- Rs.32,050
- Unit price
- per
15KW Solar DB Bundle with Fuses (Premium) is a practical 15kw solar db fuse option for Pakistani buyers who want a proper electrical product instead of improvised market stock. Starting from Rs.32,050, it is suited to real use cases in Lahore, Karachi, Islamabad, Rawalpindi,...- Rs.32,050
Rs.37,500- Rs.32,050
- Unit price
- per
-
15KW On Grid Solar DB Bundle With VA & Fuses - Maximum Protection
- Rs.45,700
- Rs.45,700
- Unit price
- per
The 15KW On Grid Solar DB Bundle With VA & Fuses is a premium 15kw solar db package for buyers who want the most complete protection path in Pakistan. Starting from Rs.45,700, this top-tier bundle combines breakers, SPDs, DC fuses, and VA voltage protection...- Rs.45,700
- Rs.45,700
- Unit price
- per
CNC Electric is Pakistan's authorised distributor of solar circuit breakers — DC-rated MCBs and MCCBs purpose-built for photovoltaic strings, battery banks, and inverter DC bus protection. Standard 500V, 1000V and 1500V DC voltage ratings, IEC 60947-2 certified, with 5-year warranty from local Lahore stock.
Solar Breaker Price in Pakistan 2026
| Type | Voltage / Amp | Application | Price (PKR) |
|---|---|---|---|
| DC MCB 2P Solar | 500V × 16-63A | 6-12 panel string | Rs. 1,600 – 1,950 |
| DC MCB 4P Solar | 1000V × 20-63A | 12-24 panel residential string | Rs. 3,400 – 3,700 |
| DC MCB 4P Commercial | 1500V × 32A | Large commercial PV plant | Rs. 3,800 – 4,220 |
| DC Battery Breaker | 500V × 125A | Inverter battery bus | Rs. 2,500 – 2,800 |
| Solar DC Isolator 4P | 1000V × 25-63A | Rooftop service disconnect | Rs. 2,800 – 4,500 |
| Solar SPD DC | 600V / 1000V / 1500V | Lightning surge protection | Rs. 2,900 – 8,600 |
| DC Fuse Holder 10×38 | 1000V × 1-30A gPV | String fuse protection | Rs. 380 – 850 |
Why You CANNOT Use AC Breakers on Solar DC
The single most dangerous mistake in Pakistani solar installs is using AC MCBs/MCCBs on the DC side. AC current crosses zero 100 times per second — the natural way arcs self-extinguish. DC current never crosses zero, so the arc keeps burning when you try to open the breaker. Within 1-3 seconds the contacts weld closed and the breaker housing melts. Fire risk is real and documented.
The CNC DC-rated breakers in this collection use twin contact pairs in series + permanent magnets to deflect the arc, achieving safe DC interruption at the rated voltage. Voltage rating must match your PV string Voc × 1.25 safety factor:
| PV String Voc | Required Breaker Voltage | CNC Model Family |
|---|---|---|
| up to 200V (6-panel) | 250V DC | YCB8-63 250V |
| 200-400V (8-12 panel) | 500V DC | YCB8-63PV 500V |
| 400-800V (residential) | 1000V DC | YCB8s-63 1000V 4P |
| 800-1200V (commercial) | 1500V DC | YCB8s-32 1500V 4P |
Complete Solar DB Protection Bundles
For one-stop solar DB protection, CNC offers pre-packaged bundles combining DC breaker + SPD + isolator + DC fuse in a single waterproof enclosure:
- 3-5kW On-Grid Bundle: 2P 32A DC MCB + 1000V SPD + 16A DC fuse — Rs. 8,500
- 5-10kW Hybrid Bundle: 4P 63A DC MCB + 1500V SPD + battery breaker + 2× DC isolator — Rs. 18,500
- 10-20kW Commercial Bundle: 100A DC MCCB + 1500V Class I+II SPD + 4-string fuse combiner — Rs. 38,500
NEPRA Net-Metering Compliance
Pakistani solar net-metering applications under NEPRA SROs require approved DC-side protection. The CNC solar breaker range complies with:
- IEC 60947-2 (DC switchgear safety)
- IEC 60364-7-712 (PV installation safety)
- NEPRA Net-Metering Reference Guide 2023 §4.2 (DC isolation requirements)
- AEDB Net-Metering Application Form, Annexure C (protection schedule)
